HD720p,1MP CMOS Sensor, 24 pcs IR LEDs, 20m IR, Outdoor IR Bullet, ICR, 0.01 Lux/F1.2, 12 VDC, Smart IR, IP66, Wide operating temperature range (-40°~60°), 2.8/3.6/6mm Lens
Camera | ||
---|---|---|
Image Sensor: | | | 1MP CMOS Image Sensor |
Signal System: | | | PAL/NTSC |
Effective Pixels: | | | 1296(H)x732(V) |
Min. Illumination: | | | 0.1 Lux @(F1.2,AGC ON), 0 Lux with IR |
Shutter Time: | | | 1/25(1/30) s to 1/50,000 s |
Lens: | | | 3.6mm (2.8mm, 6mm optional), Angle of View: 70.9°(3.6mm), 92°(2.8mm), 56.7°(6mm) |
Lens Mount: | | | M12 |
Adjustment Range: | | | Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360° |
Day& Night: | | | IR cut filter with auto switch |
Video Frame Rate: | | | 720p@25fps/720p@30fps |
HD Video Output: | | | 1 Analog HD output |
Synchronization: | | | Internal Synchronization |
S/N Ratio: | | | More than 62 dB |
General | ||
Operating Conditions: | | | -40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
Power Supply: | | | 12 VDC±15% |
Power Consumption: | | | Max. 4W |
Weather Proof: | | | IP66 |
IR Range: | | | Up to 20m |
Dimension: | | | Φ70×149.5 mm (Φ2.76” ×5.89”) |
Weight: | | | 400 g |
